HP DesignJet T730

Hinges F9A30-67019 (HP DesignJet T830 MFP only)
Removal
Tools: Screwdrivers; Torx 8, 10, 15, and 25
1. Remove the Scanner Module, see Scanner Module on page 505.
2. Remove the Top Cover Scanner, see Scanner Top Cover F9A30-67015 on page 423.
3. Remove 1 screw.
4. Remove the bracket Hinge Damper.
ENWW Hinges F9A30-67019 (HP DesignJet T830 MFP only) 437
