Paper Motor
Removal
1. Switch o the printer and remove the power cable.
2. Remove the Front Cover, Front Cover on page 261.
3. Remove the Cutter Door, see Cutter Door F9A30-67006 on page 378.
4. Remove the Left Cover, see Left Cover MFP SV Kit F9A30-67012 on page 268.
5. Remove the Main PCA, see Main PCA on page 311.
6. Remove two T-10 screws.
7. Slide the Paper Motor inwards, and hold it with a nger to stop it falling down.
ENWW Paper Motor 317
