HP DesignJet T730

Latch (Left) F9A30-67030
Removal
1. Remove the Left Cover, see Left Cover MFP SV Kit F9A30-67012 on page 268.
2. Remove the Front Panel and Left Trim, see Front Panel and Left Trim F9A30-67043 on page 526.
3. Remove the Bottom Platten, see Bottom Platen F9A30-67042 on page 431.
4. Remove 1 screw.
5. Unclip the Latch.
524 Chapter 5 Removal and installation ENWW
