Paper path (front)
HP part number Part description Removal and installation
reference
Comments
1 CQ893-67022 36 Starwheel assy SV Rep
Starwheel Assembly
on page 356
Includes the Output Shaft and
instruction ier
2 F9A30-67054 Right Gear Train SV Right Gear Train Module
on page 353
3
CQ893-67018 Output Tray Sensor SV CSR B (has no cable included);
see Out-Of-Paper Sensor ier
on page 572
4 CQ890-67019 Pro Extension/Output Tray Output Tray on page 365 CSR A
5 CQ893-67027 Output Platen New Lid 36 Output Platen on page 370
The cutter rail is not a service
part
ENWW Paper path (front) 239
