Right Optical Sensor F9A30-60187
Removal
1. Remove the Bottom Platen, see Bottom Platen F9A30-67042 on page 431.
2. Detach the cable from the Mount OPT Right Optical Sensor.
3. Remove one screw.
4. Disconnect the cable and remove the OPT Right Optical Sensor.
460 Chapter 5 Removal and installation ENWW
