Bottom of Form (BOF) Optical Sensor F9A30-60030
Removal
1. Remove the Bottom Platen, see Bottom Platen F9A30-67042 on page 431.
2. Remove one screw from the Bottom of Form Optical Sensor.
3. Disconnect and remove the Bottom of Form Optical Sensor.
Installation
▲
Install by reversing the removal process.
ENWW Sensor SV Kit F9A30-67031 455
