Cutter Bridge
The Cutter Bridge is attached to the front of the Carriage as shown below:
Removal
1. Remove the Printhead Assembly, see Replace the printhead on page 124.
2. Switch o the printer and remove the power cable.
3. (MFP only) Remove the Scanner Module, see Scanner Module on page 505.
4. Ensure that the Carriage is in the center of the Platen, where you can easily access it.
380 Chapter 5 Removal and installation ENWW
