Carriage Line Sensor
Removal
1. Switch o the printer and remove the power cable.
2. Remove the Front Cover, see Front Cover on page 261.
3. Remove the Right Cover, see Right Cover MFP SV Kit F9A30-67011 on page 264.
4. Make sure the Service Station and Carriage are located in the right position.
5. Detach the right side of the Cover PCA Carriage.
402 Chapter 5 Removal and installation ENWW
