Front Panel SFP F9A29-67008
Removal
1. Switch o the printer and remove the power cable.
2. Remove the Front Cover, see Front Cover on page 261.
3. Remove the Cutter Door, see Cutter Door F9A30-67006 on page 378.
4. Remove the Left Cover, see Left Cover MFP SV Kit F9A30-67012 on page 268.
5. Disconnect the Power Button FFC, the FP cable and the black USB cable.
6. Move up the Front Panel if it is in the at position.
278 Chapter 5 Removal and installation ENWW
