Scanner Feedshaft (Rear)
Removal
1. Remove the Bottom Platen, see Bottom Platen F9A30-67042 on page 431.
2. Unclip and rotate the right Bearing.
3. Unclip and rotate the left Bearing.
4. Remove the Scanner Feedshaft (Rear).
446 Chapter 5 Removal and installation ENWW
