HP DesignJet T730

Calibration Sliders (or Calibration Surfaces)
Overview
The calibration sliders are used as the white color calibration for the Scanbars. There are 3 sliders; one slider
for each Scanbar. The sliders are also used to hold media up against the Scanbars during scans. The normal
force is controlled by 4 springs for each slider.
