Top of Form (TOF) Optical Sensor F9A30-60035
Removal
1. Remove the Bottom Platen, see Bottom Platen F9A30-67042 on page 431.
2. Disconnect the cable from the Top of Form Optical Sensor.
3. Remove one screw.
4. Remove the Top of Form Optical Sensor.
458 Chapter 5 Removal and installation ENWW
