Load optical Sensor F9A30-60035
Removal
1. Remove the Bottom Platen, see Bottom Platen F9A30-67042 on page 431.
2. Disconnect the cable from the Load optical Sensor.
3. Remove one screw.
4. Remove the Load optical Sensor.
456 Chapter 5 Removal and installation ENWW
