Prime Pump
Removal
1. Switch o the printer and remove the power cable.
2. Remove the Front Cover, see Front Cover on page 261.
3. Remove the Right Cover, see Right Cover MFP SV Kit F9A30-67011 on page 264
4. Remove the ISS, see ISS on page 499.
5. Disconnect the cable.
6. Disconnect the tube.
340 Chapter 5 Removal and installation ENWW
