Scanner Feedshaft (Front) F9A30-67025
Removal
Tools: Screwdriver Torx 10
1. Remove the Bottom Platen, see Bottom Platen F9A30-67042 on page 431.
2. Unroute the cable.
3. Remove one screw from the Right Optical sensor.
440 Chapter 5 Removal and installation ENWW
