4. Remove the Calibration slider.
Installation
1. Install the Calibration Slider by reversing the removal process.
2. Calibration Slider replacement checklist:
a. Replace all 3 calibration sliders
b. Clean the scanbars.
c. Remove lms.
d. Boot the unit.
e. Promote PRNU to Pristine (from Extended Support Menu).
f. Run Scanbar alignment calibration.
g. Restore Scanner Calibrations (from Extended Support Menu).
NOTE: Calibrations Slider SV kit includes only 1 calibration slider. Calibration surface SV kit contains 3
calibration surfaces.
NOTE: Pay attention to the position of the shaft cam when assembling the calibration slider.
488 Chapter 5 Removal and installation ENWW
