HP DesignJet T730

Parts in alphabetical order Parts in removal order
Hinges F9A30-67019 (HP DesignJet T830 MFP only) on page 437 Multi-Sheet Tray Assembly on page 367
Input platen SV F9A30-67039 (HP DesignJet T830 MFP only)
on page 513
Multi-Sheet Tray Assembly Extensions on page 368
ISS on page 499 Output Platen on page 370
Latch (Left) F9A30-67030 on page 524 Carriage Motor on page 374
Latch (Right) F9A30-67030 on page 522 Cutter Assembly on page 378
Left Cover MFP SV Kit F9A30-67012 on page 268 Cutter Door F9A30-67006 on page 378
Left Roll Support on page 292 Cutter on page 379
Left Spittoon on page 420 Cutter Bridge on page 380
Lower Pinch Assembly with Mirror F9A30-67033 (HP DesignJet
T830 MFP only) on page 492
Cutter Guide on page 383
Main PCA on page 311 Multi-Sheet Tray Sensor Assembly on page 385
Multi-Sheet Tray Assembly on page 367 Out-Of-Paper Sensor on page 388
Multi-Sheet Tray Assembly Extensions on page 368 Out-Of-Paper Sensor Cable on page 392
OPT Wheel F9A30-60038 on page 453 Output Tray Sensor Assembly on page 395
Sensor SV Kit F9A30-67031 on page 454 Output Tray Extender Sensor Cable on page 398
Out-Of-Paper Sensor on page 388 Carriage Line Sensor on page 402
Out-Of-Paper Sensor Cable on page 392 Bundle Board on page 406
Output Platen on page 370 Bundle Board FFC cable on page 408
Output Shaft on page 358 Pinchwheels on page 414
Output Tray on page 365 Left Spittoon on page 420
Output Tray Extender Sensor Cable on page 398 Scanner Top Cover F9A30-67015 on page 423
Output Tray Sensor Assembly on page 395 Scanbars F9A30-67017 (HP DesignJet T830 MFP only)
on page 425
Paper Motor on page 317 Top Cover Button Latch F9A30-67016 (HP DesignJet T830 MFP
only) on page 430
Pinchwheels on page 414 Bottom Platen F9A30-67042 on page 431
Power Supply on page 308 Scan Bundle Board F9A30-67029 on page 433
Prime Pump on page 340 Scanner Feed Motor F9A30-67024 on page 435
Printer NVM backup PCA on page 305 Hinges F9A30-67019 (HP DesignJet T830 MFP only) on page 437
Printer Sensor Kit SV on page 473 Scanner Feedshaft (Front) F9A30-67025 on page 440
Rear Cover (MFP only) on page 464 Scanner Feedshaft (Rear) on page 446
Refeed Preventer on page 504 Bottom Cables F9A30-67034 on page 448
RIDS (Ink Tubes) on page 494 OPT Wheel F9A30-60038 on page 453
Right Cover MFP SV Kit F9A30-67011 on page 264 Sensor SV Kit F9A30-67031 on page 454
Right Gear Train Module on page 353 Rear Cover (MFP only) on page 464
Right Roll Support on page 297 Scanbar FFC F9A30-67018 on page 466
