HP DesignJet T730

Parts in alphabetical order Parts in removal order
Roll Cover on page 272 Printer Sensor Kit SV on page 473
Scan Bundle Board F9A30-67029 on page 433 Calibration Surface F9A30-67027 on page 484
Scanbars F9A30-67017 (HP DesignJet T830 MFP only)
on page 425
Calibration Slider on page 487
Scanner Feed Motor F9A30-67024 on page 435 Calibration Surface Gear Train F9A30-67028 on page 489
Scanner Feedshaft (Front) F9A30-67025 on page 440 Lower Pinch Assembly with Mirror F9A30-67033 (HP DesignJet
T830 MFP only) on page 492
Scanner Feedshaft (Rear) on page 446 RIDS (Ink Tubes) on page 494
Scanner Module on page 505 ISS on page 499
Scanbar FFC F9A30-67018 on page 466 Front Window MFP SV Kit F9A30-67013 on page 502
Scanner Top Cover F9A30-67015 on page 423 Refeed Preventer on page 504
Sensor SV Kit F9A30-67031 on page 454 Scanner Module on page 505
Service Station on page 334 Top Lid Mirror and Magnet (HP DesignJet T830 MFP only)
on page 511
Starwheel Assembly on page 356 Input platen SV F9A30-67039 (HP DesignJet T830 MFP only)
on page 513
Top window SFP F9A29-67007 on page 258 Diverter SV F9A30-67040 on page 516
Top Cover Button Latch F9A30-67016 (HP DesignJet T830 MFP
only) on page 430
Diverter bottom part F9A30-67062 on page 520
Top Lid Mirror and Magnet (HP DesignJet T830 MFP only)
on page 511
Latch (Right) F9A30-67030 on page 522
Trailing Cable on page 326 Latch (Left) F9A30-67030 on page 524
Upper-Roll Paper Guide on page 289 Front Panel and Left Trim F9A30-67043 on page 526
