11. Be sure the Cartridges Door is open (VERY IMPORTANT).
CAUTION: Failure to follow will cause potential damage to cartridge door tab.
12. Remove the Right Cover.
IMPORTANT: Remove the Right Cover with the Ink Door open and the PHA Door closed.
Installation
▲
Install the Right Cover by reversing the removal process.
ENWW Right Cover MFP SV Kit F9A30-67011 267
