8. MFP only: Open the Scanner.
9. MFP only: Remove two screws.
NOTE: A long T15 bit is required to reach the screws.
10. Remove the left cover.
Installation
▲
Install the Left Cover by reversing the removal process.
270 Chapter 5 Removal and installation ENWW
