HP DesignJet T730

13. Disconnect the two at cables from the PCA.
NOTE: Image shown is from another product, and for reference only.
14. Remove one T-15 screw from the left side.
15. Unclip the trailing cable retainer clip shown here (1) and slide it to the right (2).
ENWW Carriage and Belt 345
