4. Remove the Scan Bundle Board.
Installation
▲
Install the Scan Bundle Board by reversing the removal process.
NOTE: Once the Scanner Bundle Board is replaced, when the printer boots up a System Error
0009-0174 will appear. This is an expected behaviour. After pressing "OK" to hide the System error,
proceed to Extended Support Menu for NVM sync.
IMPORTANT: MFP only: Synchronize the Main PCA and Scan Bundle Board after Scan Bundle Board PCA
replacement: Extended Support Menu ►"Scanner save calibrations".
434 Chapter 5 Removal and installation ENWW
