3. Slide the Lower Pinch Assembly by pushing it away from you and towards the printer, and take it out
from the printer.
TIP: The pinches can be seen in the scanner output path.
4. Remove the Lower Pinch Assembly.
Installation
▲
Install the Lower Pinch Assembly with Mirror by reversing the removal process.
NOTE: The Lower Pinch Assembly position can be estimated based on the input platen mark.
ENWW Lower Pinch Assembly with Mirror F9A30-67033 (HP DesignJet T830 MFP only) 493
