Keysight M8000 Series of BER Test Solutions User Guide 315
Setting up Analyzer 6
The following figure shows a slightly modified figure for the analyzer part:
This figure is true for M8041A and M8051A modules with serial numbers
>= DE55300500.
This figure shows what the analyzer represents as termination scheme to
the DUT. The DUT would be connected to the connectors shown on the
left part of the respective schemes above.
VT VT VT
VTVT VT
SE Normal SE Complement Differential
Balanced
Unbalanced
DC
AC
ANALYZER
VT = Termination Voltage
