Keysight Technologies M8000 Series User Manual

450 Keysight M8000 Series of BER Test Solutions User Guide
7 Setting up Patterns
Trigger State
XML: triggerState
RxDetectReset
RxDetectActive,
PollingLFPS,
PollingRxEq,
PollingActive,
PollingConfiguration,
U0
RecoveryActive
RecoveryConfiguration
LoopbackActive
PollingLFPSPlus
PollingPortMatch
PollingPortConfig,
LoopbackAc
tive
This parameter determines when
the trigger output signal of the
LTSSM block should be asserted.
Additionally this information can be
translated into a trigger pulse on
entering or leaving the specified
state. This is done by the pulse
shaper of the Ctrl Out A connector
and no direct functionality of the
LTSSM.
Both
LFPS tPeriod
XML: lfps_tPeriod
10 ns – 110 ns 50 ns Period and Duty cycle of LFPS cycle Both
Duty Cycle
XML:lfps_dutyCycle
40 % - 60 % 50 %
Polling.LFPS tBurst
XML: pollingLFPS_tBurst
0.5 µs – 2 µs 1 µs Link Training handshake before
5Gb/s
USB 3.0
tRepeat
XML: pollingLFPS_tRepeat
5 µs – 20
µs
10 µs
Warm Reset
LFPS
tBurst
XML: warmResetLFPS_tBurst
80 ms – 120 ms 100 ms LFPS trigger transition to Rx.Detect Both
SCD1 and
SCD2
tBurst
XML: scd1scd2_tBurst
0.5 µs – 1.5 µs 1 µs SuperSpeedPlus Capability
Declaration (SCD) is a step for a
SuperSpeedPlus port, while in the
Polling.LFPS substate, to identify
itself as SuperSpeedPlus capable
by transmitting Polling.LFPS
signals with specific patterns
unique to SuperSpeedPlus ports.
USB 3.1
tRepeat0
XML: scd1scd2_tRepeat-0
4 µs – 11 µs 7.5 µs
tRepeat1
XML: scd1scd2_tRepeat-1
9 µs – 16 µs 12.5 µs
SuperSpeedP
lus LFPS
Based PWM
Message
(LBPM
tPWM
XML: superSpeedPlus_tPWM
1.9 µs – 2.5 us 2.2 µs LBPM is defined as a low power
signaling mechanism for two
SuperSpeedPlus ports to
communicate with each other
based on LFPS signals. The
adoption of Pulse Width
Modulation (PWM) is to embed the
transmitting clock in data and to
allow for easy data recovery at the
receiver based on LFPS clock.
USB 3.1
tLFPS-0
XML:
superSpeedPlus_tLFPS-0
0.4 µs – 0.9 us 0.750 µs
tLFPS-1
XML:
superSpeedPlus_tLFPS-1
1.23. µs – 1.9 us 1.450 µs
