MEASurement Commands 2
Keysight N8262A Programming Guide 163
READ[1]|2|3|4[:SCALar][:POWer:AC]:DIFFerence?
[<expected_value>[,<resolution>[,<source list>]]]
This command sets the specified window’s measurement function to difference
mode with relative mode off, aborts then initiates both Channel A and B,
calculates the difference measurement result and places the result on the bus.
The result is a power based measurement and is expressed in the units defined by
UNIT[1]|2|3|4:POWer.
Syntax
Parameters
Refer to “Optional Parameters” on page 126 for additional details on the
parameters in this command.
INITiate:CONTinuous must be set to OFF on both channels, otherwise error
–213, “INIT ignored” occurs. If TRIGger:SOURce is set to BUS on either channel,
error –214, “Trigger deadlock” occurs.
:POW
:AC
?
:SCAL
:DIFF
Space
expected_value
DEF
resolution
,
DEF
source list
,
READ
1
2
3
4
