12 SYSTem Subsystem
482 Keysight N8262A Programming Guide
Table 12-3 GSM900: Power meter presets: Window/Measurement settings
Function Setting
Single Channel Dual Channel
Display setup
Upper window Channel A trace
Primary channel
[a]
trace
Lower window LU single numeric See Table 12-4
Window/measurement setup
Upper window/upper measurement (UU)
Feed N/A N/A
Measurement N/A N/A
Upper window/lower measurement (UL)
Feed N/A N/A
Measurement N/A N/A
Lower window/upper measurement (LU)
Feed Gate 1 Channel A
Gate 1 primary channel
[a]
Measurement Avg Avg
Lower window/lower measurement (LL)
Feed DEF See Table 12-4
Measurement DEF See Table 12-4
[a] For further information refer to “Primary and Secondary Channels” on page 473.
Table 12-4 GSM900: Power meter presets for secondary channel sensors
Function Secondary Channel Sensor
No Sensor Non P-Series P-Series
Display setup
Lower window LU single numeric Dual numeric Dual numeric
