12 SYSTem Subsystem
516 Keysight N8262A Programming Guide
Trace setup
[SENS[1]]|SENS2:TRAC:OFFS:TIME
<numeric_value>
–40 µs
Delay between delayed trigger point and
the start of the trace
[SENS[1]]|SENS2:TRAC:TIME
<numeric_value>
1 ms Length of the trace
[a] The Range setting in Table 12-32 is only applicable for E-Series power sensor.
Table 12-32 1xeV-DO: Power meter presets (continued)
Command Setting Comments
Table 12-33 1 exV-DO: Power meter presets: Window/Measurement settings
Function Setting
Single Channel Dual Channel
Display setup
Upper window Channel A trace
Primary channel
[a]
trace
Lower window Dual numeric See Table 12-34
Window/measurement setup
Upper window/upper measurement (UU)
Feed N/A N/A
Measurement N/A N/A
Upper window/lower measurement (UL)
Feed N/A N/A
Measurement N/A N/A
Lower window/upper measurement (LU)
Feed Gate 1 Channel A
Gate 1 primary channel
*
Measurement Avg Avg
Lower window/lower measurement (LL)
