SYSTem Subsystem 12
Keysight N8262A Programming Guide 485
Averaging
[SENSe[1]]|SENSe2:AVER[:STATe] ON Averaging On
[SENSe[1]]|SENSe2:AVER:COUN 64 Averaging set to 64
Step detection
[SENSe[1]]|SENS2:AVER:SDET 1 Step detection enabled
Trace setup
SENSe[1]|2:TRAC:LIM:UPP +20 dBm Maximum power
SENSe[1]|2:TRAC:LIM:LOW –35 dBm Minimum power
[SENS[1]]|SENS2:TRAC:OFFS:TIME
<numeric_value>
–40 µs Delay between delayed trigger point and
the start of the trace
[SENS[1]]|SENS2:TRAC:TIME
<numeric_value>
700 µs Length of the trace
Table 12-5 EDGE: Power meter presets (continued)
Command Setting Comments
The Range setting in Table 12-5 is only applicable for E-Series power sensor.
Table 12-6 EDGE: Power meter presets: Window/Measurement settings
Function Setting
Single Channel Dual Channel
Display setup
Upper window Channel A trace
Primary channel
[a]
trace
Lower window Dual numeric See Table 12-7
Window/measurement setup
Upper window/upper measurement (UU)
Feed N/A N/A
