12 SYSTem Subsystem
526 Keysight N8262A Programming Guide
[SENS[1]]|SENS2:POW:AC:RANG:AUTO OFF Auto range off
[SENS[1]]|SENS2:POW:AC:RANG UPPER Range set to upper
Step detection
[SENSe[1]]|SENS2:AVER:SDET 1 Step detection enabled
Trace setup
SENSe[1]|2:TRAC:LIM:UPP +20 dBm Maximum power
SENSe[1]|2:TRAC:LIM:LOW -35 dBm Minimum power
[SENS[1]]|SENS2:TRAC:OFFS:TIME
<numeric_value>
-0.2 ms Delay between delayed trigger point and
the start of the trace
[SENS[1]]|SENS2:TRAC:TIME
<numeric_value>
28 ms Length of the trace
[a] The Range setting in Table 12-41 is only applicable for E-Series power sensor.
Table 12-41 NADC: Power meter presets (continued)
Command Setting Comments
Table 12-42 NADC: Power meter presets: Window/Measurement settings
Function Setting
Single Channel Dual Channel
Display setup
Upper window Channel A trace
Primary channel
[a]
trace
Lower window Dual numeric See Table 12-43
Window/measurement setup
Upper window/upper measurement (UU)
Feed N/A N/A
Measurement N/A N/A
Upper window/lower measurement (UL)
Feed N/A N/A
