12 SYSTem Subsystem
510 Keysight N8262A Programming Guide
Table 12-27 802.11a and HiperLan2: Power meter presets: Window/Measurement settings
Function Setting
Single Channel Dual Channel
Display setup
Upper window UU Single Numeric UU Single Numeric
Lower window Dual numeric See Table 12-28
Window/measurement setup
Upper window/upper measurement (UU)
Feed Gate 1 Channel A
Gate 1 primary channel
[a]
Measurement Avg Avg
Upper window/lower measurement (UL)
Feed DEF See Table 12-28
Measurement DEF See Table 12-28
Lower window/upper measurement (LU)
Feed Gate 1 Channel A See Table 12-28
Measurement Peak See Table 12-28
Lower window/lower measurement (LL)
Feed Gate 1 Channel A See Table 12-28
Measurement Pk-to-Avg See Table 12-28
[a] For further information refer to “Primary and Secondary Channels” on page 473.
