SYSTem Subsystem 12
Keysight N8262A Programming Guide 469
SYSTem:HELP:HEADers?
This query returns a list of all SCPI commands supported by the instrument.
Data is returned in IEEE 488.2 arbitrary block program data format as shown in
Figure 12-1 below.
Figure 12-1 IEEE 488.2 Arbitrary block program data format
Each point in the trace is represented as an IEEE 754 32 bit floating point number,
made up of four bytes in the data block. The MS byte is transmitted first. Each
complete block is terminated by a line feed.
Commands are listed in alphabetical order.
Syntax
Example
#xyyy..yddd..................ddd<LF>
The number of y digits
Signifies the start of the block
The number of data bytes (d)
contained in the block.
Data bytes
Line feed character
signifies the end of the block
Example: if there are 12435 data bytes, y = 12435 and x = 5
SYST:HELP:HEAD? This command returns the SCPI commands
supported by the instrument.
