12 SYSTem Subsystem
522 Keysight N8262A Programming Guide
[SENS[1]]|SENS2:SWE[1]|2|3|4:TIME Gate 1: 810 µs
Gates 2 - 4: 0
Length of time gated period for time gated
measurements.
Trigger setup
TRIG[:SEQ[1]|2]:SOUR INT1
Trigger source set up and acquisition
mode continuous triggering
INIT:CONT ON
TRIG[:SEQ]:LEV:AUTO ON
Enable automatic setting of the trigger
level
TRIG[:SEQ]:LEV AUTO Power level
TRIG[:SEQ]:SLOP POS
Trigger event recognized on the rising
edge of a signal
TRIG[:SEQ]:DEL 0 s
Delay between recognition of trigger event
and start of a measurement
TRIG[:SEQ]:HOLD 1 ms Trigger holdoff
Range
[a]
[SENS[1]]|SENS2:POW:AC:RANG:AUTO OFF Auto range off
[SENS[1]]|SENS2:POW:AC:RANG UPPER Range set to upper
Step detection
[SENSe[1]]|SENS2:AVER:SDET 0 Step detection disabled
Trace setup
[SENS[1]]|SENS2:TRAC:OFFS:TIME
<numeric_value>
–40 µs
Delay between delayed trigger point and
the start of the trace
[SENS[1]]|SENS2:TRAC:TIME
<numeric_value>
1 ms Length of the trace
[a] The Range setting in Table 12-38 is only applicable for E-Series power sensor.
Table 12-38 TD-SCDMA: Power meter presets (continued)
