Range
[a]
[SENS[1]]|SENS2:POW:AC:RANG:AUTO OFF Auto range off
[SENS[1]]|SENS2:POW:AC:RANG UPPER Range set to upper
Step detection
[SENSe[1]]|SENS2:AVER:SDET 1 Step detection enabled
[a] The Range setting in Table 12-47 is only applicable for E-Series power sensor.
Table 12-47 DVB: Power meter presets (continued)
Command Setting Comments
Table 12-48 DVB: Power meter presets: Window/Measurement settings
Function Setting
Single Channel Dual Channel
Display setup
Upper window UU single numeric See Table 12-49
Lower window Dual numeric See Table 12-49
Window/measurement setup
Upper window/upper measurement (UU)
Feed Gate 1 Channel A
Gate 1 primary channel
[a]
Measurement Avg Avg
Upper window/lower measurement (UL)
Feed DEF See Table 12-49
Measurement DEF See Table 12-49
Lower window/upper measurement (LU)
Feed Gate 1 Channel A See Table 12-49
Measurement Pk-to-Avg See Table 12-49
Lower window/lower measurement (LL)
