Keysight Technologies P Series

12 SYSTem Subsystem
534 Keysight N8262A Programming Guide
Feed Gate 2 Channel A See Table 12-49
Measurement Avg See Table 12-49
[a] For further information refer to “Primary and Secondary Channels” on page 473.
Table 12-48 DVB: Power meter presets: Window/Measurement settings (continued)
Function Setting
Single Channel Dual Channel
Table 12-49 DVB: Power meter presets for secondary channel sensors
Function Secondary Channel Sensor
No Sensor Non P-Series Sensor P-Series Sensor
Display setup
Upper window UU single numeric Dual numeric Dual numeric
Lower window Dual numeric Dual numeric Dual numeric
Upper window/lower measurement (UL)
Feed DEF
Gate 1 primary channel
[a]
Gate 1 primary channel
[a]
(Channel A)
Measurement DEF Pk-to-Avg Pk-to-Avg
Lower window/upper measurement (LU)
Feed
Gate 1 primary channel
[a]
Gate 2 primary channel
[a]
Gate 1 secondary channel
[a]
(Channel B)
Measurement Pk-to-Avg Avg Avg
Lower window/lower measurement (LL)
Feed
Gate 2 primary channel
[a]
Secondary channel
[a]
Gate 1 secondary channel
[a]
(Channel B)
Measurement Avg Avg Pk-to-Avg
[a] For further information refer to “Primary and Secondary Channels” on page 473.
