12 SYSTem Subsystem
486 Keysight N8262A Programming Guide
Measurement N/A N/A
Upper window/lower measurement (UL)
Feed N/A N/A
Measurement N/A N/A
Lower window/upper measurement (LU)
Feed Gate 1 Channel A
Gate 1 primary channel
[a]
Measurement Avg Avg
Lower window/lower measurement (LL)
Feed Gate 1 Channel A See Table 12-7
Measurement Pk-to-Avg See Table 12-7
[a] For further information refer to “Primary and Secondary Channels” on page 473.
Table 12-6 EDGE: Power meter presets: Window/Measurement settings (continued)
Function Setting
Single Channel Dual Channel
Table 12-7 EDGE: Power meter presets for secondary channel sensors
Function Secondary Channel Sensor
No Sensor Non P-Series Sensor P-Series Sensor
Display setup
Lower window Dual numeric Dual numeric Dual numeric
Lower window/lower measurement (LL)
Feed
Gate 1 primary channel
*
Secondary channel
[a]
Gate1 secondary channel
[a]
(Channel B)
Measurement Pk-to-Avg Avg Avg
[a] For further information refer to “Primary and Secondary Channels” on page 473.
