EDGE
EDGE (Enhanced Data for Global Evolution or Enhanced Data for GSM Evolution)
is an enhancement of the GSM standard. Whereas the GSM modulation scheme is
GMSK which has constant amplitude, the EDGE modulation scheme is 8PSK
which has variable amplitude.
The EDGE set-up provides:
– Average power measurement in an EDGE burst.
– Peak-to-average ratio in an EDGE burst.
– A trace display of the burst profile
An EDGE measurement is started by detecting the rising edge of the EDGE RF
burst—for example the burst emitted by a mobile—using the internal RF level
trigger. The internal level trigger is set to –20 dBm. Trigger level hysteresis is used
to prevent the power meter re-triggering on the varying power levels within the
EDGE burst. Time-gating is used to measure the average power and the
peak-to-average ratio in the useful part of the RF burst.
The following table shows the power meter presets when <character_data> is
set to EDGE. Commands not listed are preset according to their DEFault values
(for further information refer to Table 12-1).
Lower window/lower measurement (LL)
Feed DEF
Secondary channel
[a]
Gate1 secondary channel
[a]
(Channel B)
Measurement DEF Avg Avg
[a] For further information refer to “Primary and Secondary Channels” on page 473.
Table 12-4 GSM900: Power meter presets for secondary channel sensors (continued)
Function Secondary Channel Sensor
No Sensor Non P-Series P-Series
