SYSTem Subsystem 12
Keysight N8262A Programming Guide 501
Table 12-18 BLUetooth: Power meter presets: Window/Measurement settings
Function Setting
Single Channel Dual Channel
Display setup
Upper window Channel A trace
Primary channel
[a]
trace
Lower window Dual numeric See Table 12-19
Window/measurement setup
Upper window/upper measurement (UU)
Feed N/A N/A
Measurement N/A N/A
Upper window/lower measurement (UL)
Feed N/A N/A
Measurement N/A N/A
Lower window/upper measurement (LU)
Feed Gate 1 Channel A
Gate 1 primary channel
[a]
Measurement Avg Avg
Lower window/lower measurement (LL)
Feed Gate 1 Channel A See Table 12-19
Measurement Peak See Table 12-19
[a] For further information refer to “Primary and Secondary Channels” on page 473.
