802.11a and HiperLan2
The following table shows the power meter presets when <character_data> is
set to 802DOT11A and HIPERLAN2. Commands not listed are preset according to
their DEFault values (for further information refer to Table 12-1).
Table 12-25 RADAR: Power meter presets for secondary channel sensors
Function Secondary Channel Sensor
No Sensor Non P-Series Sensor P-Series Sensor
Display setup
Upper window Primary Channel Trace Dual numeric Dual numeric
Lower window Dual numeric Dual numeric Dual numeric
Upper window/upper measurement (UU)
Feed
Gate 1 primary channel
[a]
Gate 1 primary channel
[a]
Gate 1 primary channel
[a]
Measurement Pk-to-Avg Peak Peak
Upper window/lower measurement (UL)
Feed 1
Gate 2 primary channel
[a]
Gate 1 primary channel
[a]
Gate 1 primary channel
[a]
Feed 2
Measurement Avg Peak Avg
Lower window/upper measurement (LU)
Feed 1
Gate 1 primary channel
[a]
Gate 2 primary channel
[a]
Gate1 secondary channel
[a]
(Channel B)
Feed 2
Measurement Peak Avg Peak
Lower window/lower measurement (LL)
Feed
Gate 1 primary channel
[a]
Secondary channel
[a]
Gate1 secondary channel
[a]
(Channel B)
Measurement Avg Avg Avg
[a] For further information refer to “Primary and Secondary Channels” on page 473.
