12 SYSTem Subsystem
528 Keysight N8262A Programming Guide
iDEN
The iDEN set-up provides:
– Average power in one iDEN training and data pulse
– Peak-to-average one iDEN training and data pulse
– Average power in a 90ms iDEN frame
The measurement is started by detecting the iDEN training burst—for example the
burst emitted by a mobile—using the internal RF level trigger. Time gating is used
to measure the average power in the following 15 ms (data pulse). Gate 1 is used
to measure this data pulse. The 90 ms frame is also captured to measure the
average power in the entire frame. Gate 2 is used to measure the 90 ms frame.
The following table shows the power meter presets when <character_data> is
set to IDEN. Commands not listed are preset according to their DEFault values (for
further information refer to Table 12-1):
Table 12-44 iDEN: Power meter presets
Command Setting Comments
Frequency
[SENS[1]]|SENS2:FREQ[:CW|:FIX] +800.000 MHz Frequency setting
Sensor measurement mode
[SENS[1]]|SENS2:DET:FUNC NORM Measurement mode
Sensor video bandwidth setup
[SENS[1]]|SENS2:BAND|BWID:VID N1921/2A: OFF Sensor video bandwidth
Gate Setup
[SENS[1]]|SENS2:SWE[1]|2|3|4:OFF:TIME
Gate 1: 0
µs
Gates 2 - 4: 0
Delay between trigger point and time
gated period.
[SENS[1]]|SENS2:SWE[1]|2|3|4:TIME Gate 1: 15 ms
Gate 2: 90 ms
Gate 3: 160
µs
Gate 4: 0
Length of time gated period for time gated
measurements.
