Group 8 Job editor Page 247
JET2 neo Release R1.12 en
The following table shows the explanations for each step and setting.
No.
Explanation
1
Before the first data are received the set wildcards represent the first
display buffer content. This would also be the first print-out as soon as
a PrintGo signal will be received.
2
The character string 1ab456 is sent to the printer starting with the
character 1.
3, 5, 7, 9, 11
The display buffer remains the same because the input buffer is not
filled up completely.
4, 6, 8, 10
The characters a, b, 4 and 5 are sent.
12
The character 6 is sent. With that character the input buffer is
completely filled.
13
With the input buffer filled up completely the content is transferred to
the display buffer.
14
The input buffer is emptied after the transfer in the last step. This state
can also be set with the <Deleting ExternText memory>command.
15
Parameters object 1: 1 wildcard (X) and 0 offset
16
Display content for object 1: the first character of the display buffer.
17
Parameters object 2: 2 wildcards (YY) and 1 offset (OS)
18
Display content for object 1: the second and the third character of the
display buffer
19
Parameters object 3: 3 wildcards (ZZZ) and 3 offset (OS)
20
Display content object 3: the fourth, fifth and sixth character of the
display buffer.
8.6.6.1 Mailing
The mailing function allows using ExternText objects as placeholders for external data.
These data have to be provided through the Ethernet interface of the printer using the
commands of the JET2neo interface protocol and the JET2neo script language.
Basic mode of operation (please see Figure 147) :
The interface has to be set to <Ethernet> (1) (please see chapter 8.6.6.1.1 Extern Text:
Interface settings).
After an ExternText object is created (please see chapter 8.6.6.1.2 Extern Text: Object
settings and properties) the settings of the object are specified in the dialog box for the
<Object settings> (2) on the <Extern Text> tab (3). The object type <Mailing> (4) is
selected and a data field is assigned to the object (5). The settings for <Wildcards> and
the <Wildcard> characters are entered the same way as for the ExternText object (6).
The number of the <Wildcards> define the number of the characters of the data field set
which shall be printed. There can be defined several ExternText objects and they can be
assigned to different data fields (7).
