Omron FQ2-S/CH Series

Menu Tables
440
FQ2-S/CH User’s Manual
Image adjustment
(Color Gray Filter)
Filter type
You can specify the ranges of colors to
which the Color Gray Filter item is
applied.
• RGB (Default)
•HSV
Scene p. 96
Filter settings Select the type of color filter to use.
• Red filter (Default)
• Green filter
• Blue filter
• Cyan filter
• Magenta filter
• Yellow filter
• Brgt.F. (R+G+B)
• Brgt.F. (R+2G+B)
• Custom filter
Scene p. 96
Source image You must set the image to which the filter
is to be applied.
•Camera
• Prev. (Default)
Scene p. 95
(Items other than Color Gray Filter)
Filter region You can specify the region to which to
apply the filter.
--- Scene p. 95
Source image You must set the image to which the filter
is to be applied.
•Camera
• Prev. (Default)
Scene p. 95
Suppression level
(for Background
Suppression Item
Only)
The range in which to enhance the con-
trast and the brightness range to extract
are set for the Background Suppression
item.
--- Scene p. 98
Basic
Teach
for Search Position Compensation、 Shape Search Position Compensation, and Shape
Search Position lll Compensation
Model region
Used to specify the region of the image
to register as the model with a combina-
tion of figures.
--- Scene ---
Add
• Rectangle
• Ellipse
• Wide circle
•Polygon
Scene
---
Delete --- Scene
Copy --- Scene ---
Console --- Scene ---
OR/NOT • OR (Default)
•NOT
Scene ---
One/All • One (Default)
•All
Scene ---
Insp. region Adjusts the size and position of the mea-
surement region.
--- Scene ---
Detection
point
You can specify which part of the model
to detect as coordinates during inspec-
tions.
--- Scene ---
Menu command Description Setting range Data
