FQ2-S/CH User’s Manual
*1 Refer to FQ2-S/CH Series User's Manual for Communications Settings (Cat. No. Z338).
Image adjustment (Position compensation items)
Details
Model parameters
(Shape Search and
Shape Search lll Posi-
tion Compensation
Items only)
• Shape Search Position Compensation Item and Search Position Compensa-
tion Item
Almost the same as for the Shape Search III, Shape Search II, and Search
inspection item.
However, the [Sub-pixel] and [Multi-point output] settings of the Search
inspection item do not exist.
•
Edge Position Compensation, Two-edge Position Compensation, Two-edge Mid-
point Compensation, and Edge Rotation Position Compensation
The settings for the Edge Position Compensation item are almost the same as
those for the Edge Position inspection item.
Scene ---
Meas. Parameter Scene ---
Output parameter
Scene ---
Scroll parameter
Source image
You can select the image to which to
apply the results of position compensa-
tion processing.
Camera
Prev. (Default)
Scene p. 107
Interpolation You can select the precision of position
compensation.
Bilinear
None (Default)
Scene p. 108
for Position Compensation (Image rotation, Parameter)
Image rotation
Select to correct the position by rotating
the image around the center of the
screen.
−180° to 180° (Default: 90°) Scene p. 126
Parameter
Reference position
Reference
position X
coordinate
Sets the X coordinate of the reference
position.
−99999 to 99999
(Default: p. 127)
Scene
p. 126
Reference
position Y
coordinate
Sets the Y coordinate of the reference
position.
−99999 to 99999
(Default: p. 127)
Scene
Reference
angle Sets the reference angle θ. −180 to 180 (Default: 90) Scene
Measurement position
Measure-
ment posi-
tion X
coordinate
Sets the X coordinate of the measure-
ment position.
−99999 to 99999
(Default: p. 127) Scene
Measure-
ment posi-
tion Y
coordinate
Sets the Y coordinate of the measure-
ment position.
−99999 to 99999
(Default: p. 127) Scene
Measure-
ment angle
Sets the measurement angle θ. −180 to 180 (Default: 0)
Scene
for Linear Correction
Ref. position Sets the reference position. --- Scene p. 129
Meas. position Sets the measurement position. --- Scene p. 129
Filter region You can specify the range over which
position correction is performed.
--- Scene p. 131
Source image You must set the image to which the filter
is to be applied.
Camera
Prev. (Default) Scene p. 132
Interpolation You can select the precision of position
compensation.
None
Bilinear (Default)
Scene
p. 132
Menu command Description Setting range Data
