Omron FQ2-S/CH Series User Manual

Menu Tables
FQ2-S/CH User’s Manual
473
Appendices
9
*1 Refer to FQ2-S/CH Series User's Manual for Communications Settings (Cat. No. Z338).
*2 Not supported on the FQ2-S1/S2/S3 Series.
*3 Not supported on the FQ2-CH Series.
TF settings
SD card
SD card
informa-
tion
Displays the capacity and remaining mem-
ory in the SD card. --- Touch
Finder
data
p. 411
Format Formats an SD card. --- p. 412
Startup dis-
play
Startup
screen
type
You can select the display to appear on
the Touch Finder when more than one
Sensor is connected.
Multi Sensor
NG sensor
Single sensor
Auto (Default)
Touch
Finder
data
p. 389
Specify
sensor
You can specify one Sensor to connect to
the Touch Finder.
ON
OFF (Default)
p. 417
Display
pattern
Sets the display to use in Run Mode.
(Only appears when [Start screen type] under
[Startup display] is set to [Single sensor].)
Graphic Graphics + Details
All results/Region Statistical data
Trend monitor Histogram
p. 356
p. 416
Display
update
mode
Sets the image to update in Run Mode.
Latest image
Last NG image p. 383
LCD back-
light
Brightness Sets the brightness. 0 to 5 Touch
Finder
data
p. 384
ECO
mode
Enables (ON) or disables (OFF) ECO
Mode.
ON
OFF
p. 384
Ethernet --- Touch
Finder
data
p. 67
DHCP Used to automatically connect to the IP
address of the Touch Finder.
OFF (Default)
ON
p. 67
IP address
I
nputs the IP address of the Touch Finder.
(Valid only when the [IP address setting] is
set to [Fixed].)
a.b.c.d
a:1 to 223
b: 0 to 255
c: 0 to 255
d: 0 to 255
(Default: 10.5.5.10) Touch
Finder
data
p. 67
Subnet mask
Inputs the subnet mask.
(Valid only when the [IP address setting] is
set to [Fixed].)
0.0.0.0 to 255.255.255.255
(Default: 255.255.255.0)
p. 67
Gateway
Sets the Default gateway address. (When
the [IP address setting] is set to [Fixed].)
1.0.0.1 to 223.255.255.254
(Default: 10.5.5.1)
p. 67
Auto sensor detection The Touch Finder can detect Sensors and
automatically connect to them in the order
that it detects them.
ON
OFF (Default)
Touch
Finder
data
p. 386
Logging setting You must enable file logging before you
can execute it.
ON (Default)
OFF
p. 399
Language Changes the language to display on the
Touch Finder.
English, German
French, Italian, Spanish,
Traditional Chinese
Simplified Chinese
Korean, Japanese
(The Default language is selected at
startup.)
p. 427
Time settings Used to set the current date and time. Default: Selected at startup. --- p. 427
Touch screen calib Used when there is an offset between the
touch screen positions and pointers.
--- --- p. 427
Initialize Initializes the Touch Finder settings. --- --- p. 428
Restart Restarts the Touch Finder. --- --- p. 428
Update Updates the Touch Finder system to the
most recent data.
--- --- p. 573
Re-assign IP forcibly Executed when a sensor on the same net-
work cannot be detected and the sensor's
IP address is not known.
--- --- p. 436
