Ricoh B079 - Page 277

Service
Tables
SERVICE PROGRAM MODE TABLES
SM 5-51 B079/B082
SP5 Mode Number Function and [Setting]
10* Unique ID Lists the ID (Node_Unique_ID) assigned to the
device by the system administrator.
[0~1/1/1]
0: Does not list the Node_Unique_ID assigned by
the system administrator. Instead, the
Source_ID of the GASP header in the ARP is
used.
1: The Node_Unique_ID assigned by the system
administrator is used, and the Source_ID of the
GASP header in the ARP is ignored. Also, when th
e
serial bus is reset, extra bus transactions are
opened for the enumeration.
11* Logout Handles the login request of the login initiator for
SBP-2. (1-bit)
[0~1/1/1]
0: Disable (refuse login)
Initiator retry during login
Login refusal on arrival of login request
(standard operation)
1: Enable (force logout)
Initiator retry during login
Login refusal on arrival of login request, and the
initiator forces the login.
12* Login Enables or disables the exclusive login feature
(SBP-2 related).
[0~1/0/1]
0: Disables. The exclusive login (LOGIN ORB
exClusvie it) is ignored.
1: Enables. Exclusive login is in effect.
5839
13* Login MAX Sets the maximum number of logins from the
initiator (6-bits)
[0~63/8/1]
0: Reserved
63: Reserved
IEEE 802.11b
4 SSID Enters an unique ID (up to 32 characters long) to
identify the device when it is operating in an area
with another wireless LAN network.
5840
6 Channel MAX Sets the maximum number of channels available
for data transmission via the wireless LAN. The
number of channels available varies according to
location. The default settings are set for the
maximum end of the range for each area. Adjust
the upper 4 bits to set the maximum number of
channels.
JA [1~14/ 14 / 1]
NA [1~14 / 14 / 1
EU [1~13 / 13 / 1]
China, Taiwan (Same as NA)
Displayed only when the option 802.11b for
wireless LAN is installed.
