SERVICE PROGRAM MODE TABLES
B079/B082 5-56 SM
SP5 Mode Number Function and [Setting]
Debug Log Save Function
1 On/Off (1:ON 0:OFF) Switches the debug log feature on and off. The
debug log cannot be captured until this feature is
switched on.
[0 ~ 1 / 0 / 1]
0: OFF
1: ON
2 Target (1:IC Card 2:HDD) Select “1” (IC Card) if an HDD unit is not installed in
the machine, or if the HDD unit is temporarily out of
service. The IC card can store only 4 MB so use th
HDD selection.
3 Initialize IC Card Initializes the IC card inserted into the controller
slot. Initializing erases all data on the IC card. Use
to initialize a new card. DFU
4 Save to IC Card Saves the debug log in memory to the IC card. DF
existing file names on the SD Card. Up to 4MB can
be copied to an SD Card. 4 MB segments can be
copied one by one to each SD Card.
7 HDD to IC Card (Latest
4MB)
Copies the latest 4 MB of the debug log on the
HDD to the IC card. This function erases all data
from the IC card as it copies.
8 HDD to IC Card (Latest
4MB Any Key)
Copies the latest 4 MB of the debug log on the
HDD to the IC card, but only those portions of the
log specified with a key specified with SP5859
(Debug Save Key No.) This function erases all data
from the IC card as it copies.
To enable this SP, the machine must be cycled off
and on.
5857
11 Erase Debug Data From
HDD
Erases all debug log data from the IC card. DFU.
Debug Log Save Function These SPs select the content of the debugging
information to be saved to the destination selected
by SP5857 002.
1 Engine SC Error Stores SC codes generated by copier engine
errors.
2 Controller SC Error Stores SC codes generated by GW controller
errors.
3 Any SC Error Stores one SC specified by number.
[0~65535 / 0 / 1]
Refer to Section 4 for a list of SC error codes.
5858
4 Jam Stores jam errors.
Debug Log Save Function
1 Key 1
2 Key 2
3 Key 3
4 Key 4
5 Key 5
6 Key 6
7 Key 7
5859
8 Key 8
These SPs allow you to set up to 10 keys for log
files for functions that use common memory on the
controller board. (!5.3.1)
[-9999999~9999999 / 0 / 1]
