BIT SWITCHES
B547 54 SM
FAX Switch 0C SP No. 1-102-013
No FUNCTION COMMENTS
0
Action when an original jam
has occurred while scanning
the original into memory for
memory tx
0: Continues scanning after
recovery
1: Stops scanning and erases
all scanned pages for that job
This bit is only effective when parallel memory tx is
disabled (user parameter 07 - bit 2).
If parallel memory tx is enabled, the machine always
erases the scanned pages when an original jam
occurs. The machine then asks the user to retry
from the first page, even if the parallel memory tx is
not actually used.
0: The machine displays a message asking the user
to put the jammed page back into the original stack,
and continues scanning.
The message is displayed for the time period
specified by scanner switch 0E, bit 2.
1: The machine erases all the scanned pages and
asks the user to retry from the first page.
1
to
2
Setting when an original size
cannot be recognized
Bit 2 1 Setting
0 0 No original
0 1 A5
1 0 A5
1 1 No original
3-5 Not used Do not change the settings.
6
Scan width used for a
document set in the ADF when
the width is less than 230 mm.
0: A4 (210 mm)
1: LT (216 mm)
This bit is set at “1” when the country code is set to
the US.
7 Not used Do not change the setting.
FAX Switch 0D SP No. 1-102-014
No FUNCTION COMMENTS
0-6 Not used Do not change the settings.
7
Scan width for A5 lengthwise or
B5 lengthwise originals
0: 210 mm (8.5”)
1: Original width
0: The machine scans the original as 210 mm (8.5")
width. The transmitted image has a blank area on
the right.
1: The machine scans 148 mm (A5) or 182 mm (B5)
and centers the scanned data on a 216 mm width
transmitted image.
