BOOKLET FINISHER INSTALLATION (B546)
B079/B082 1-56 SM
9. Set the hooks [A] of the shift tray [B] in the notches in the shift tray bracket, and
secure the tray with two M4 x 6 screws.
10. Connect the shift tray sensor harness [C].
11. Install the harness cover [D] (2 hooks).
B546I106.WMF
B546I107.WMF
[A]
[B]
[C]
[D]
