Bit Switches – 4
D0CK 90 SM
6 Reconstruction time for
the first line in receive
mode
0: 6s 1: 12s
When the sending terminal is controlled by a computer, there may
be a delay in receiving page data after the local machine accepts
set-up data and sends CFR. This is outside the T.30
recommendation. But, if this delay occurs, set this bit to 1 to give
the sending machine more time to send data.
Refer to error code 0-20.
ITU-
T T.30 recommendation: The first line should come within 5 s of
CFR.
7 Not used Do not change the settings.
G3 Switch 0B - Not used (do not change the settings).
G3 Switch 0C (SP No. 1-105-013)
No Function Comments
0-
3
Not used Do not change these settings.
4-
5
Select detection of DTMF/DP detection
when using remote switch.
00: DTMF+PSTN (Simultaneous
detection)
01: DTMF
10: DP (10 PPPS)
11: DP (20 PPS)
This setting determines how to detect the signals
from the handset when remote switch is active.
6-
7
Not used Do not change these settings.
G3 Switch 0D - Not used (do not change the settings).
G3 Switch 0E (SP No. 1-105-015)
No Function Comments
0-
7
Set CNG send time interval
Some machines on the receiving side may not be able to automatically switch the 3-second
CNG interval.
High order bit 3000-2250ms: 3000-50xNms
3000 – 50 x Nms 0F (3000 ms) <= N <= FF (2250 ms)
Low order bit 00-0E(3000-3700ms: 3000+50xNms
3000 – 50 x Nms 0F (3000 ms) <= N <= 0F (3700 ms)
