Dehumidification Heater (main unit)
SM 2-115 D0CA/D0C9/D0C8/D0CB
• A:For the dehumidification heater (H3)
• B:For the junction harness
• C:Not used (For the isolation cap)
• D:Isolation cap
• The connector [C] is not used. Put the connector into the opening.
4. Put the mainframe on the table.
5. Remove the upper left cover [A].
6. Pull out the paper feed tray.
